Aggregate Units

The Hiteco aggregate units come from a distant past, when in 1985, as an inside department of SCM, Hiteco designed the first electro spindle with automatic tool changer for the woodworking industry and at the same time a full range of aggregate units.

Thanks to the automatic tool changer and Hiteco aggregate units, woodworking machines have acquired a high level of operational flexibility that was crucial to the market success these machines have achieved in subsequent years.

Today Hiteco is on the market with a new range of aggregate units that have been specifically designed to offer maximum precision and reliability.

Download Catalogue

view video



COPY ER 32 H=175

  • 1 end Aggregate unit
  • Height: 175 mm
  • Tool holder posiiton: vertical
  • Tool shankdiameter: 2-20 mm
  • Weight: 5 kg

COPY ER 32 H=175

  • 1 end Aggregate unit
  • Height: 175 mm
  • Tool holder posiiton: vertical
  • Tool shankdiameter: 2-20 mm
  • Weight: 5 kg

D SIDE ER20 H=195

  • 1 end Aggregate unit
  • Height: 195 mm
  • Tool holder posiiton: vertical fixed
  • Tool holder: ER20
  • Weight: 6 kg

D SIDE ER20 H=195

  • 1 end Aggregate unit
  • Height: 195 mm
  • Tool holder posiiton: vertical fixed
  • Tool holder: ER20
  • Weight: 6 kg

FOUR ER25 H=100

  • 4 ends Aggregate unit
  • Height: 100 mm
  • Tool holder posiiton: 90°
  • Tool holder: ER25 MINI
  • Weight: 5,6 kg

FOUR ER25 H=100

  • 4 ends Aggregate unit
  • Height: 100 mm
  • Tool holder posiiton: 90°
  • Tool holder: ER25 MINI
  • Weight: 5,6 kg

FOUR ER25 H=145

  • 4 ends Aggregate unit
  • Height: 145 mm
  • Tool holder posiiton: 90°
  • Tool holder: ER25 MINI
  • Weight: 5,6 kg

FOUR ER25 H=145

  • 4 ends Aggregate unit
  • Height: 145 mm
  • Tool holder posiiton: 90°
  • Tool holder: ER25 MINI
  • Weight: 5,6 kg

FOUR ER25 H=180

  • 4 ends Aggregate unit
  • Height: 180 mm
  • Tool holder posiiton: 90°
  • Tool holder: ER25 MINI
  • Weight: 5,6 kg

FOUR ER25 H=180

  • 4 ends Aggregate unit
  • Height: 180 mm
  • Tool holder posiiton: 90°
  • Tool holder: ER25 MINI
  • Weight: 5,6 kg

HORIZONTAL LOW BORE H=178

  • 3 horizontal ends Aggregate unit
  • Height: 178 mm
  • Tool holder posiiton: horizontal
  • Tool holder: Ø8 H7 (0/+0.015) mm
  • Weight: 6 kg

HORIZONTAL LOW BORE H=178

  • 3 horizontal ends Aggregate unit
  • Height: 178 mm
  • Tool holder posiiton: horizontal
  • Tool holder: Ø8 H7 (0/+0.015) mm
  • Weight: 6 kg

MULTIBLADE H=100

  • 1 end multiblade Aggregate unit
  • Height: 100 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 5 kg

MULTIBLADE H=100

  • 1 end multiblade Aggregate unit
  • Height: 100 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 5 kg

MULTIBLADE H=145

  • 1 end multiblade Aggregate unit
  • Height: 145 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 5 kg

MULTIBLADE H=145

  • 1 end multiblade Aggregate unit
  • Height: 145 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 5 kg

MULTIBLADE H=180

  • 1 end multiblade Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 5 kg

MULTIBLADE H=180

  • 1 end multiblade Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 5 kg

NOTCH FRESA H=180

  • 1 end Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 160 mm
  • Weight: 5 kg

NOTCH FRESA H=180

  • 1 end Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 160 mm
  • Weight: 5 kg

NOTCH H=180

  • 1 end Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 160 mm
  • Weight: 5 kg

NOTCH H=180

  • 1 end Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 160 mm
  • Weight: 5 kg

ONE BLADE H=100

  • 1 end Aggregate unit
  • Height: 100 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 4,2 kg

ONE BLADE H=100

  • 1 end Aggregate unit
  • Height: 100 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 4,2 kg

ONE BLADE H=145

  • 1 end Aggregate unit
  • Height: 145 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 4,2 kg

ONE BLADE H=145

  • 1 end Aggregate unit
  • Height: 145 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 4,2 kg

ONE BLADE H=180

  • 1 end Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 4,2 kg

ONE BLADE H=180

  • 1 end Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Blade diameter: 240 mm
  • Weight: 4,2 kg

ONE ER32 H=100

  • 1 end Aggregate unit
  • Height: 100 mm
  • Blade coupling position: 90°
  • Tool holder: ER32 DX
  • Weight: 4,2 kg

ONE ER32 H=100

  • 1 end Aggregate unit
  • Height: 100 mm
  • Blade coupling position: 90°
  • Tool holder: ER32 DX
  • Weight: 4,2 kg

ONE ER32 H=145

  • 1 end Aggregate unit
  • Height: 180 mm
  • Blade coupling position: 90°
  • Tool holder: ER32 DX
  • Weight: 4,2 kg

ONE ER32 H=145

  • 1 end Aggregate unit
  • Height: 180 mm
  • Blade coupling position: 90°
  • Tool holder: ER32 DX
  • Weight: 4,2 kg

ONE ER32 H=180

  • 1 end Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Tool holder: ER32 DX
  • Weight: 4,2 kg

ONE ER32 H=180

  • 1 end Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Tool holder: ER32 DX
  • Weight: 4,2 kg

THREE ER32-ER25B-ER25 H=100

  • 3 ends Aggregate unit
  • Height: 100 mm
  • Tool holder posiiton: horizontal + vertical
  • Tool shankdiameter: ER32 2-20 ER25 2-16
  • Blade diameter: 240 mm
  • Weight: 5.5 kg

THREE ER32-ER25B-ER25 H=100

  • 3 ends Aggregate unit
  • Height: 100 mm
  • Tool holder posiiton: horizontal + vertical
  • Tool shankdiameter: ER32 2-20 ER25 2-16
  • Blade diameter: 240 mm
  • Weight: 5.5 kg

TILT BLADE ER20B H115

  • 1 end Aggregate unit
  • Height: 115 mm
  • Blade coupling posiiton: adjustable
  • Tool holder: ER20B
  • Blade diameter: 240 mm
  • Weight: 5 kg

TILT BLADE ER20B H115

  • 1 end Aggregate unit
  • Height: 115 mm
  • Blade coupling posiiton: adjustable
  • Tool holder: ER20B
  • Blade diameter: 240 mm
  • Weight: 5 kg

TILT ER25 H=115

  • 1 end Aggregate unit
  • Height: 115 mm
  • Blade coupling posiiton: adjustable
  • Tool holder: ER25 MINI
  • Blade diameter: 240 mm
  • Weight: 5 kg

TILT ER25 H=115

  • 1 end Aggregate unit
  • Height: 115 mm
  • Blade coupling posiiton: adjustable
  • Tool holder: ER25 MINI
  • Blade diameter: 240 mm
  • Weight: 5 kg

TWIN H=100

  • 2 ends Aggregate unit
  • Height: 100 mm
  • Blade coupling posiiton: 90°
  • Tool holders: ER32 DX - ER25 SX MINI
  • Blade diameter: 240 mm
  • Weight: 5 kg

TWIN H=100

  • 2 ends Aggregate unit
  • Height: 100 mm
  • Blade coupling posiiton: 90°
  • Tool holders: ER32 DX - ER25 SX MINI
  • Blade diameter: 240 mm
  • Weight: 5 kg

TWIN H=145

  • 2 ends Aggregate unit
  • Height: 145 mm
  • Blade coupling posiiton: 90°
  • Tool holders: ER32 DX - ER25 SX MINI
  • Blade diameter: 240 mm
  • Weight: 5 kg

TWIN H=145

  • 2 ends Aggregate unit
  • Height: 145 mm
  • Blade coupling posiiton: 90°
  • Tool holders: ER32 DX - ER25 SX MINI
  • Blade diameter: 240 mm
  • Weight: 5 kg

TWIN H=180

  • 2 ends Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Tool holders: ER32 DX - ER25 SX MINI
  • Blade diameter: 240 mm
  • Weight: 5 kg

TWIN H=180

  • 2 ends Aggregate unit
  • Height: 180 mm
  • Blade coupling posiiton: 90°
  • Tool holders: ER32 DX - ER25 SX MINI
  • Blade diameter: 240 mm
  • Weight: 5 kg

TWIN PRO H=180

  • 2 ends Aggregate unit
  • Height: 100 mm
  • Blade coupling posiiton: 90°
  • Tool holders: ER32 DX - ER25 SX MINI
  • Tool shankdiameter: 2-16 mm
  • Weight: 5.7 kg

TWIN PRO H=180

  • 2 ends Aggregate unit
  • Height: 100 mm
  • Blade coupling posiiton: 90°
  • Tool holders: ER32 DX - ER25 SX MINI
  • Tool shankdiameter: 2-16 mm
  • Weight: 5.7 kg

VERTICAL BORE 3 SPINDLES

  • 3 vertical ends Aggregate unit
  • Height: 145 mm
  • Tool holders position: vertical
  • Tool holders: Ø10 H7 (0/+0.015) mm
  • Weight: 4 kg

VERTICAL BORE 3 SPINDLES

  • 3 vertical ends Aggregate unit
  • Height: 145 mm
  • Tool holders position: vertical
  • Tool holders: Ø10 H7 (0/+0.015) mm
  • Weight: 4 kg

VERTICAL BORE 3/4 SPINDLES

  • 3 or 4 vertical ends Aggregate unit
  • Tool holders position: vertical
  • Weight: 2.5 kg

VERTICAL BORE 3/4 SPINDLES

  • 3 or 4 vertical ends Aggregate unit
  • Tool holders position: vertical
  • Weight: 2.5 kg

VERTICAL BORE 5 SPINDLES

  • 5 vertical ends Aggregate unit
  • Height: 145 mm
  • Tool holders position: vertical
  • Tool holders: Ø10 H7 (0/+0.015) mm
  • Weight: 5 kg

VERTICAL BORE 5 SPINDLES

  • 5 vertical ends Aggregate unit
  • Height: 145 mm
  • Tool holders position: vertical
  • Tool holders: Ø10 H7 (0/+0.015) mm
  • Weight: 5 kg

VERTICAL BORE 6 SPINDLES

  • 6 vertical ends Aggregate unit
  • Tool holders position: vertical
  • Weight: 2.5 kg

VERTICAL BORE 6 SPINDLES

  • 6 vertical ends Aggregate unit
  • Tool holders position: vertical
  • Weight: 2.5 kg
