Bi-Rotary Units

With over 15 years of experience, Hiteco has produced more than 1,500 units for woodworking and its derivatives, plastics and aluminum. The Hiteco operating units are used for production of furniture, doors, roofs and wooden walls as well as in other sectors such as railways, automotive and aerospace.

The units are made in advantageous configuration with 5th rotary axis tilted or in the traditional configuration with horizontal 5th rotary axis, in both cases with or without brakes stiffening static 4th and 5th axis

Download Catalogue

ORBITAL HPX 100

  • Power electrospindle: 10 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 615 mm
  • Servomotor: Yaskawa

ORBITAL HPX 100

  • Power electrospindle: 10 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 615 mm
  • Servomotor: Yaskawa

ORBITAL HPX 150

  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 615 mm
  • Servomotor: Yaskawa

ORBITAL HPX 150

  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 615 mm
  • Servomotor: Yaskawa

ORBITAL HPX 180

  • Power electrospindle: 18 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 615 mm
  • Servomotor: Yaskawa

ORBITAL HPX 180

  • Power electrospindle: 18 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 615 mm
  • Servomotor: Yaskawa

ORBITAL HPX 200

  • Power electrospindle: 20 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 615 mm
  • Servomotor: Yaskawa

ORBITAL HPX 200

  • Power electrospindle: 20 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 615 mm
  • Servomotor: Yaskawa

ORBITAL JQX 100

  • Power electrospindle: 10 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa

ORBITAL JQX 100

  • Power electrospindle: 10 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa

ORBITAL JQX 110

  • Power electrospindle: 11 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa

ORBITAL JQX 110

  • Power electrospindle: 11 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa

ORBITAL JQX 50 Compressed Air

  • Power electrospindle: 5 kw @ 12000 rpm
  • V max electrospindle: 21000 rpm
  • Cooling: Compressed Air
  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa

ORBITAL JQX 50 Compressed Air

  • Power electrospindle: 5 kw @ 12000 rpm
  • V max electrospindle: 21000 rpm
  • Cooling: Compressed Air
  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa

ORBITAL JQX 80 HIGH SPEED 36000 rpm

  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 8 kw @ 15000 rpm
  • V max electrospindle: 36000 rpm
  • Cooling: Liquid

ORBITAL JQX 80 HIGH SPEED 36000 rpm

  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 8 kw @ 15000 rpm
  • V max electrospindle: 36000 rpm
  • Cooling: Liquid

ORBITAL JQX 80 HIGH SPEED 40000 rpm

  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 8 kw @ 15000 rpm
  • V max electrospindle: 40000 rpm
  • Cooling: Liquid

ORBITAL JQX 80 HIGH SPEED 40000 rpm

  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 8 kw @ 15000 rpm
  • V max electrospindle: 40000 rpm
  • Cooling: Liquid

ORBITAL JQX 85

  • Power electrospindle: 8.5 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa

ORBITAL JQX 85

  • Power electrospindle: 8.5 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa

ORBITAL KPX 100

  • Power electrospindle: 10 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 570 mm
  • Servomotor: Yaskawa

ORBITAL KPX 100

  • Power electrospindle: 10 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 570 mm
  • Servomotor: Yaskawa

ORBITAL KPX 120

  • Power electrospindle: 12 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 570 mm
  • Servomotor: Yaskawa

ORBITAL KPX 120

  • Power electrospindle: 12 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 570 mm
  • Servomotor: Yaskawa

ORBITAL KPX 150

  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 570 mm
  • Servomotor: Yaskawa

ORBITAL KPX 150

  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
  • Axes Angle: 50°
  • Overall dimension: 570 mm
  • Servomotor: Yaskawa

TILT H-PLUS HX 130

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 13 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT H-PLUS HX 130

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 13 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT H-PLUS HX 150

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT H-PLUS HX 150

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT H-PLUS HX 180

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 18 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT H-PLUS HX 180

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 18 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT H-PLUS HX 200 (Synchronous)

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 20 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT H-PLUS HX 200 (Synchronous)

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 20 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT HPX 100

  • Axes Angle: 90°
  • Overall dimension: 501 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 10 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT HPX 100

  • Axes Angle: 90°
  • Overall dimension: 501 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 10 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT HPX 150

  • Axes Angle: 90°
  • Overall dimension: 501 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT HPX 150

  • Axes Angle: 90°
  • Overall dimension: 501 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT HPX 180

  • Axes Angle: 90°
  • Overall dimension: 501 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 18 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT HPX 180

  • Axes Angle: 90°
  • Overall dimension: 501 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 18 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT HPX 200

  • Axes Angle: 90°
  • Overall dimension: 501 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 20 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT HPX 200

  • Axes Angle: 90°
  • Overall dimension: 501 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 20 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT JQX 100

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 10 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT JQX 100

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 10 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT JQX 110

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 11 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT JQX 110

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 11 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT JQX 50 COMPRESSED AIR

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 5 kw @ 12000 rpm
  • V max electrospindle: 21000 rpm
  • Cooling: Compressed Air

TILT JQX 50 COMPRESSED AIR

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 5 kw @ 12000 rpm
  • V max electrospindle: 21000 rpm
  • Cooling: Compressed Air

TILT JQX 80 HIGH SPEED 36000 rpm

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 8 kw @ 15000 rpm
  • V max electrospindle: 36000 rpm
  • Cooling: Liquid

TILT JQX 80 HIGH SPEED 36000 rpm

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 8 kw @ 15000 rpm
  • V max electrospindle: 36000 rpm
  • Cooling: Liquid

TILT JQX 80 HIGH SPEED 40000 rpm

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 8 kw @ 15000 rpm
  • V max electrospindle: 40000 rpm
  • Cooling: Liquid

TILT JQX 80 HIGH SPEED 40000 rpm

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 8 kw @ 15000 rpm
  • V max electrospindle: 40000 rpm
  • Cooling: Liquid

TILT JQX 85

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 8.5 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT JQX 85

  • Axes Angle: 90°
  • Overall dimension: 480 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 8.5 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT K-PLUS HX 120

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 12 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT K-PLUS HX 120

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 12 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT K-PLUS HX 130

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 13 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT K-PLUS HX 130

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 13 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT K-PLUS HX 150

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT K-PLUS HX 150

  • Axes Angle: 90°
  • Overall dimension: 630 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT KPX 100

  • Axes Angle: 90°
  • Overall dimension: 500 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 10 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT KPX 100

  • Axes Angle: 90°
  • Overall dimension: 500 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 10 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT KPX 120

  • Axes Angle: 90°
  • Overall dimension: 500 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 12 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT KPX 120

  • Axes Angle: 90°
  • Overall dimension: 500 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 12 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT KPX 150

  • Axes Angle: 90°
  • Overall dimension: 500 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT KPX 150

  • Axes Angle: 90°
  • Overall dimension: 500 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 15 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT QHT 160

  • Axes Angle: 90°
  • Overall dimension: 640 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 16 kw @ 6000 rpm
  • V max electrospindle: 16000 rpm
  • Cooling: Liquid

TILT QHT 160

  • Axes Angle: 90°
  • Overall dimension: 640 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 16 kw @ 6000 rpm
  • V max electrospindle: 16000 rpm
  • Cooling: Liquid

TILT QHT 250

  • Axes Angle: 90°
  • Overall dimension: 640 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 25 kw @ 7000 rpm
  • V max electrospindle: 16000 rpm
  • Cooling: Liquid

TILT QHT 250

  • Axes Angle: 90°
  • Overall dimension: 640 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 25 kw @ 7000 rpm
  • V max electrospindle: 16000 rpm
  • Cooling: Liquid

TILT TLP QM-2 63A ES

  • Axes Angle: 90°
  • Overall dimension: 676 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 30 kw @ 6000 rpm
  • V max electrospindle: 13000 rpm
  • Cooling: Liquid

TILT TLP QM-2 63A ES

  • Axes Angle: 90°
  • Overall dimension: 676 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 30 kw @ 6000 rpm
  • V max electrospindle: 13000 rpm
  • Cooling: Liquid

TILT TLP QM-2 80F

  • Axes Angle: 90°
  • Overall dimension: 676 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 30 kw @ 6000 rpm
  • V max electrospindle: 13000 rpm
  • Cooling: Liquid

TILT TLP QM-2 80F

  • Axes Angle: 90°
  • Overall dimension: 676 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 30 kw @ 6000 rpm
  • V max electrospindle: 13000 rpm
  • Cooling: Liquid

TILT TLP QM-2 85S

  • Axes Angle: 90°
  • Overall dimension: 676 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 30 kw @ 6000 rpm
  • V max electrospindle: 13000 rpm
  • Cooling: Liquid

TILT TLP QM-2 85S

  • Axes Angle: 90°
  • Overall dimension: 676 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 30 kw @ 6000 rpm
  • V max electrospindle: 13000 rpm
  • Cooling: Liquid

TILT VHT 250

  • Axes Angle: 90°
  • Overall dimension: 640 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 25 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT VHT 250

  • Axes Angle: 90°
  • Overall dimension: 640 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 25 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT VHX 180

  • Axes Angle: 90°
  • Overall dimension: 640 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 18 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT VHX 180

  • Axes Angle: 90°
  • Overall dimension: 640 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 18 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT VHX 200

  • Axes Angle: 90°
  • Overall dimension: 640 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 20 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT VHX 200

  • Axes Angle: 90°
  • Overall dimension: 640 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 20 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT WHX 130

  • Axes Angle: 90°
  • Overall dimension: 282 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 13 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT WHX 130

  • Axes Angle: 90°
  • Overall dimension: 282 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 13 kw @ 7000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT WHX 180

  • Axes Angle: 90°
  • Overall dimension: 282 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 18 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT WHX 180

  • Axes Angle: 90°
  • Overall dimension: 282 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 18 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT WHX 180

  • Axes Angle: 90°
  • Overall dimension: 282 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 25 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT WHX 180

  • Axes Angle: 90°
  • Overall dimension: 282 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 25 kw @ 10000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT WHX 200

  • Axes Angle: 90°
  • Overall dimension: 282 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 20 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid

TILT WHX 200

  • Axes Angle: 90°
  • Overall dimension: 282 mm
  • Servomotor: Yaskawa (other engine brands are available on demand)
  • Power electrospindle: 20 kw @ 12000 rpm
  • V max electrospindle: 24000 rpm
  • Cooling: Liquid
